Home ProductsDrone Battery200 Cycles Drone Rechargeable Battery 22.2V 30000 mAh Battery 60A Continuous Discharge 200 Cycles
200 Cycles Drone Rechargeable Battery 22.2V 30000 mAh Battery 60A Continuous Discharge 200 Cycles
200 Cycles Drone Rechargeable Battery 22.2V 30000 mAh Battery 60A Continuous Discharge 200 Cycles 200 Cycles Drone Rechargeable Battery 22.2V 30000 mAh Battery 60A Continuous Discharge 200 Cycles

200 Cycles Drone Rechargeable Battery 22.2V 30000 mAh Battery 60A Continuous Discharge 200 Cycles

Product Details:
Place of Origin: China
Brand Name: OiD
Certification: CE UL RoHS UN38.3
Model Number: OiDA988188-30000-5C-22.2
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: $0.5 ~ $100.0 / pcs
Delivery Time: 3 ~ 7 days for storage
Payment Terms: TT, L/C, Western Union
Contact Now
  • Detail Information
  • Product Description

Detail Information
Name: Drone Battery Battery Type: 22.2V 30000mAh Rechargeable
ODM: Free Custom Design For Packs Cycle Life: 200+ Cycles
Operating Temperature: -20°C~60°C Charging/ Discharging: 15A/60A
Compatibility: XT90S-F (discharge), JST-XHR-7P (charge) Weight/ Size: 2480g/209 × 92.5 × 66.5mm
Highlight:

200 Cycles Drone Rechargeable Battery

,

22.2V 30000 mAh Battery

,

30000 mAh Battery 60A

Product Description

OiDA988188-30000-5C-22.2 Drone Battery 22.2V 30000mAh 60A Continuous Discharge 200 Cycles

Product Name

OiDA988188-30000-5C-22.2 Drone Battery

Advantages

  • High energy density for extended drone flight time.
  • Optimized for high-current discharge (5C rate).
  • Lightweight design with robust performance.

Specifications

Parameter

Value

Nominal Voltage

22.2V (6S1P)

Capacity

30000mAh (Typical) / 28800mAh (Min)

Internal Impedance

7.76±1.5mΩ (1KHz AC Method)

Max Continuous Discharge

60A (2C)

Peak Discharge (≤3s)

150A (5C)

Max Charge Current

15A (0.5C, 3h Fast Charge)

Standard Charge Current

6.0A (0.2C, 7.5h)

Dimensions (L × W × H)

209 × 92.5 × 66.5mm (Max)

Weight

2480±100g

Terminals

XT90S-F (discharge), JST-XHR-7P (charge)

Cycle Life

Condition

Performance

0.5C CC/CV charge (25.2V), 60A discharge (18V), 25±3°C

≥200 cycles (≥80% capacity retention)

Discharge Curve

(Note: Curve data not provided; refer to manufacturer for detailed graphs.)

Operating Temperature Range

Operation

Temperature Range

Current Limit

Standard Charge

10–45°C

≤0.2C (6.0A)

Fast Charge

10–45°C

≤0.5C (15A)

Standard Discharge

-20–60°C

≤60A (2C)

High-Rate Discharge

10–45°C

≤60A (2C)

Storage (≤3 months)

-10–45°C

21.6–23.4V (3.6–3.9V/cell)

Certifications

Complies with GB31241-2014/GB/T 18287-2013 (China National Standard).

Key Features

  • 5C discharge capability for high-power drone applications.
  • 6S1P configuration with balanced voltage output.
  • Lightweight design (2.48kg) for improved payload efficiency.

Applications

  • Industrial and commercial drones.
  • High-performance UAVs.
  • Heavy-lift RC models.

Usage Warnings & Precautions

  • Do not exceed 25.5V (4.25V/cell) during charging.
  • Avoid short circuits; use insulated tools for assembly.
  • Do not discharge below 17.1V (2.85V/cell) to prevent damage.
  • Soldering: ≤350°C for ≤3s, max 5 times per terminal.

Storage Guidelines

  • Long-term (3+ months): Store at 21.6–23.4V (-10–45°C, 65±20% RH).
  • Activation: Every 3 months with 0.2C charge/discharge cycle.

Warranty & Disclaimer

  • 12-month warranty from shipment date.
  • Void if misused (e.g., over-discharge, improper storage, physical damage).









200 Cycles Drone Rechargeable Battery 22.2V 30000 mAh Battery 60A Continuous Discharge 200 Cycles 0

Usage Warnings & Precautions:

  • Avoid overcharging and deep discharging to maintain optimal performance.
  • Handle with care to prevent physical damage.
  • Do not expose the battery to extreme temperatures or flames.

Storage Guidelines:

  • Store in a cool, dry place with a temperature range of 20°C to 25°C for optimal preservation.
  • For long-term storage, charge to between 21.6V and 23.4V and store at ambient temperatures between -10°C to 45°C.

Warranty & Disclaimer:

  • 12-month limited warranty against manufacturing defects.
  • The manufacturer is not responsible for damages resulting from improper handling, storage, or usage outside of the specified conditions.
