3.2V 4200mAh LiFePo4 26650 Battery 12.6A Discharge 2000+ Cycles

3.2V 4200mAh LiFePo4 26650 Battery 12.6A Discharge 2000+ Cycles

Products - LiFePo4 Battery
  • Highlight

    12.6A Lifepo4 26650 Battery

    ,

    3.2V 4200mAh Rechargeable Battery

    ,

    4200mAh Rechargeable Battery Lightweight

  • Name
    Lifepo4 26650 Battery
  • ODM
    Free Custom Design For Packs
  • Battery Type
    4200mAh Rechargeable
  • Superior Safety & Stability
    Safe LiFePo4 Chemistry
  • Exceptional Lifespan
    2000+ Cycles
  • High-Temperature Resistance
    -20°C To 60°C
  • Eco-Friendly & Non-Toxic
    Cobalt-free Chemistry, Non-hazardous Materials
  • Cost-Effective Long-Term Value
    Lower Total Ownership Cost
  • Place of Origin
    China
  • Brand Name
    OiD
  • Certification
    Complies with UN38.3, CE, RoHS, and IEC 62133 safety standards
  • Model Number
    IFR26650N42A12.6
  • Minimum Order Quantity
    100pcs
  • Price
    $0.5 ~ $100.0 / pcs
  • Delivery Time
    3 ~ 7 days for storage
  • Payment Terms
    TT,L/C,Western Union

3.2V 4200mAh LiFePo4 26650 Battery 12.6A Discharge 2000+ Cycles

  • 3.2V 4200mAh LiFePo4 26650 Battery 12.6A Discharge 2000+ Cycles
  • 3.2V 4200mAh LiFePo4 26650 Battery 12.6A Discharge 2000+ Cycles
  • 3.2V 4200mAh LiFePo4 26650 Battery 12.6A Discharge 2000+ Cycles
  • 3.2V 4200mAh LiFePo4 26650 Battery 12.6A Discharge 2000+ Cycles
Get Price Contact Now

IFR26650N42A12.6 LiFePo4 Battery 3.2V 4200mAh 12.6A Discharge 2000+ Cycles

Product Name

IFR26650N42A12.6 LiFePo4 Battery Cell

Advantages

  • High Discharge Capability: Supports up to 12.6A (3C) continuous discharge for power-intensive tasks.
  • Long Cycle Life: 2000+ cycles with ≥80% capacity retention.
  • Lightweight Design: Ultra-compact and portable for space-sensitive applications.
  • Safe LiFePo4 Chemistry: Inherent stability with minimal thermal runaway risk.
  • Efficient Charging: 0.5C (2100mA) rated charge current.

Specifications

Parameter

Value

Model

IFR26650N42A12.6

Nominal Voltage

3.2V

Nominal Capacity

4200mAh

Energy

13.44Wh

Internal Resistance

≤25mΩ

Max Continuous Charge Current

2100mA (0.5C)

Max Continuous Discharge Current

12600mA (3C)

Charging Voltage

3.65V

Discharge Cut-off Voltage

2.0V

Weight

92g

Dimensions (Diameter × Height)

26.5mm × 66.5mm

Cycle Life

Cycles

Capacity Retention

Test Conditions

1000 cycles

≥90%

0.5C Charge/Discharge, 25°C

2000 cycles

≥80%

0.5C Charge/Discharge, 25°C

Operating Temperature Range

Mode

Temperature Range

Max Current (Charge/Discharge)

Charging

0°C to 45°C

2100mA (0.5C)

Discharging

-20°C to 60°C

12600mA (3C)

Discharge Curve

3.2V 4200mAh LiFePo4 26650 Battery 12.6A Discharge 2000+ Cycles 0

Certifications

  • Complies with UN38.3, CE, RoHS, and IEC 62133 safety standards.

Key Features

  • Compact Energy Storage: 13.44Wh capacity in a slim 26650 format.
  • Low Self-Discharge: <3% monthly loss during idle storage.
  • Durable Terminal Compatibility: Standard connectors for easy integration.

Applications

  1. Portable Lighting: High-lumen flashlights, camping lanterns.
  2. Consumer Electronics: Wireless speakers, portable fans, and drones.
  3. Power Tools: Compact cordless screwdrivers and mini grinders.
  4. Backup Systems: Emergency alarms, security cameras, and IoT devices.
  5. DIY Projects: Hobbyist robotics and small-scale energy storage prototypes.

3.2V 4200mAh LiFePo4 26650 Battery 12.6A Discharge 2000+ Cycles 1

Usage Warnings & Precautions

  • ⚠️ Never charge above 45°C or discharge below -20°C to prevent irreversible cell damage.
  • Use only LiFePo4-specific chargers with 3.65V voltage control.
  • Avoid terminal short circuits, physical impacts, or exposure to liquids.
  • Ensure proper insulation during installation.

Storage Guidelines

  • Optimal Storage SOC: 30%-50% (2.8V-3.3V per cell).
  • Storage Temperature: -10°C to 35°C (dry, non-condensing environment).
  • Recharge Interval: Every 6 months for long-term stored batteries.

Warranty & Disclaimer

  • Warranty: 24-month limited warranty against manufacturing defects.
  • Disclaimer: Warranty void if misused (e.g., over-discharge, extreme temperatures). Dispose responsibly per local regulations.
