Home ProductsLithium Ion BatteryOiD571828N255 3.7V 255mAh 1C Discharge 500 Cycles for pet tracking devices
OiD571828N255 3.7V 255mAh 1C Discharge 500 Cycles for pet tracking devices
OiD571828N255 3.7V 255mAh 1C Discharge 500 Cycles for pet tracking devices OiD571828N255 3.7V 255mAh 1C Discharge 500 Cycles for pet tracking devices

OiD571828N255 3.7V 255mAh 1C Discharge 500 Cycles for pet tracking devices

Product Details:
Place of Origin: China
Brand Name: OiD
Certification: Compliant with solid-state Li-ion battery standards: GB/T 18287-2013, IEC/EN 61960, UL 1642.
Model Number: OiD571828N255
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: $0.5 ~ $100.0 / pcs
Delivery Time: 3 ~ 7 days for storage
Payment Terms: TT, L/C, Western Union
Contact Now
  • Detail Information
  • Product Description

Detail Information
Name: Lithium Ion Battery Battery Type: 3.7V, 255mAh Rechargeable
ODM: Free Custom Design For Packs High Energy Density: 250-300Wh/kg
Superior Cold Weather Performance: Reliable In Extreme Cold (-20°C To 60°C) Cycle Life: 500+ Cycles
Charging/ Discharging: 1C/ 1C Flexible Form Factor: Thin, Customizable Pouch Design Lithium Ion Battery
Highlight:

3.7v 2a lithium battery

,

3.7v lithium ion battery

,

1c 2a lithium battery

Product Description

Product Name

Pet Li-ion Battery (Model: OiD571828N255)


Advantages

  • Compact and lightweight design (Approx. 4.5g)
  • High energy density and stable performance
  • Built-in protection circuit for safety
  • RoHS compliant

Specifications

Parameter

Value

Nominal Voltage

3.7V

Nominal Capacity

255mAh (0.2C discharge)

Minimal Capacity

≥250mAh

Charging Voltage

4.2V

Discharge Cut-off Voltage

3.0V

Standard Charging Current

0.2C

Max Charging Current

1.0C (20°C–45°C)

Standard Discharging Current

0.2C

Max Discharging Current

1.0C (25°C–60°C)

Peak Discharge Current

400mA (0.01S)

Impedance

≤150mΩ (1kHz AC)

Weight

Approx. 4.5g

Dimensions (L × W × T)

28.0mm × 17.9mm × 5.7mm (pre-swelling)


Cycle Life

Test Condition

Performance

0.2C charge/discharge cycles at 23±2°C

≥500 cycles (≥80% capacity retention)


Discharge Curve

OiD571828N255 3.7V 255mAh 1C Discharge 500 Cycles for pet tracking devices 0


Operating Temperature Range

Condition

Temperature Range

Performance

Charging

0°C to 45°C

Max 1.0C (20°C–45°C)

Discharging

-20°C to 60°C

Max 1.0C (25°C–60°C)

Storage (50% SOC)

-10°C to 25°C

≥85% capacity retention (12 months)

-10°C to 45°C

≥85% capacity retention (6 months)

-10°C to 55°C

≥90% capacity retention (1 month)


Certifications

  • Compliant with Li-ion battery standards: GB/T 18287-2013, IEC/EN 61960, UL 1642.

Key Features

  • NTC thermistor for temperature monitoring.
  • Overcharge/over-discharge/short-circuit protection.
  • Low self-discharge rate.
  • Customizable connector options (e.g., JST-ACHR-03V-S).

Applications

  • Pet tracking devices
  • Wearable electronics
  • IoT sensors
  • Portable medical devices

OiD571828N255 3.7V 255mAh 1C Discharge 500 Cycles for pet tracking devices 1

Usage Warnings & Precautions

  • Use only with specified chargers.
  • Avoid short-circuiting, crushing, or exposure to water.
  • Discontinue use if swelling, leakage, or overheating occurs.
  • Keep away from children and pets.

Storage Guidelines

  • Store at 20±5°C (recommended).
  • Maintain 50% SOC for long-term storage.
  • Recharge every 3 months to 60% capacity if unused.

Warranty & Disclaimer

  • 12-month warranty from shipment date.
  • Misuse or unauthorized modifications void warranty.
