OID 3.2V 100Ah LiFePO4 Battery with 3000 Cycles and 1C Continuous Discharge for Energy Storage

OID 3.2V 100Ah LiFePO4 Battery with 3000 Cycles and 1C Continuous Discharge for Energy Storage

Products - LiFePo4 Battery
  • Nominal Voltage
    3.2V
  • Place of Origin
    Shenzhen, China
  • Brand Name
    OID
  • Certification
    CE, RoHS, UN38.3 (Reference to standard LFP manufacturing compliance)
  • Model Number
    OID53173200F206AH
  • Minimum Order Quantity
    1pcs
  • Price
    Negotiable
  • Packaging Details
    Standard export carton with foam protection
  • Delivery Time
    5-10 business days
  • Payment Terms
    L/C,D/A,D/P,T/T,Western Union
  • Supply Ability
    5000 units per month

OID 3.2V 100Ah LiFePO4 Battery with 3000 Cycles and 1C Continuous Discharge for Energy Storage

  • OID 3.2V 100Ah LiFePO4 Battery with 3000 Cycles and 1C Continuous Discharge for Energy Storage
  • OID 3.2V 100Ah LiFePO4 Battery with 3000 Cycles and 1C Continuous Discharge for Energy Storage
Get Price Contact Now

OID 3.2V 100Ah LiFePO4 Battery (Model: OID53173200F206AH)

A high-performance, deep-cycle lithium iron phosphate cell engineered for demanding energy storage and electric vehicle applications. Manufactured under strict quality standards, this cell delivers exceptional cycle life and thermal stability.

Key Features

  • Long Cycle Life: Achieve 3000 cycles at 80% depth of discharge (DoD) under standard conditions.
  • High Discharge Current: Supports 1.0C continuous discharge and 3.0C pulse discharge (10s).
  • Wide Operating Temperature: Reliable charging from 0°C to 60°C and discharging from -20°C to 60°C.
  • Stable Chemistry: Safe LiFePO4 chemistry with excellent thermal stability and no thermal runaway.
  • Pre-load Requirement: Designed for system integration with recommended preload (500N-5000N) to optimize performance.

Detailed Specifications

Parameter Specification
Nominal Capacity 100Ah (0.5C, 25±2°C)
Nominal Voltage 3.2V
Standard Charge / Discharge Current 0.5C
Max Continuous Charge / Discharge Current 1.0C
Charge Voltage 3.65V
Discharge Cut-off Voltage 2.5V (0°C to 60°C) / 2.0V (-20°C to 0°C)
Internal Impedance ≤0.40mΩ (1KHz AC)
Cell Weight 2.15±0.1Kg
Dimensions (L×W×H) 47.8±0.5mm × 174.2±0.8mm × 132.3±0.8mm
Terminal Type M6 Threaded Hole (Pitch 1.0mm)

For more details or custom solutions, contact Jianheng at alan@liion-batt.com.
