22.8V 32000mAh Drone Battery 96A Discharge 240 Cycles

22.8V 32000mAh Drone Battery 96A Discharge 240 Cycles

Products - Drone Battery
  • Highlight

    22.8V 32000 mAh Battery

    ,

    96A Continuous Discharge Battery

    ,

    Continuous Discharge Battery 32000mAh

  • Name
    32000 MAh Battery
  • Battery Type
    22.8V 32000mAh Rechargeable
  • ODM
    Free Custom Design For Packs
  • Charging/ Discharging
    32A/96A
  • Cycle Life
    240+ Cycles
  • Operating Temperature
    -20°C~60°C
  • Compatibility
    25.0±0.2mm Tabs, 20.0±1.0mm Exposed
  • Weight/ Size
    3500g/199.5× 119 × 10mm
  • Place of Origin
    China
  • Brand Name
    OiD
  • Certification
    Complies with GB31241-2014/GB/T 18287-2013 (China National Standard).
  • Model Number
    OiDA3C0200-32000-10C-22.8
  • Minimum Order Quantity
    100pcs
  • Price
    $0.5 ~ $100.0 / pcs
  • Delivery Time
    3 ~ 7 days for storage
  • Payment Terms
    TT,L/C,Western Union

22.8V 32000mAh Drone Battery 96A Discharge 240 Cycles

  • 22.8V 32000mAh Drone Battery 96A Discharge 240 Cycles
  • 22.8V 32000mAh Drone Battery 96A Discharge 240 Cycles
Get Price Contact Now

OiDA3C0200-32000-10C-22.8 Drone Battery 22.8V 32000mAh 96A Continuous Discharge 240 Cycles

Product Name

OiDA3C0200-32000-10C-22.8 Drone Battery

Advantages

  • High energy density for extended flight time.
  • Robust performance under extreme temperatures.
  • Optimized for high-current applications.

Specifications

Parameter

Value

Nominal Voltage

22.8V

Capacity

32000mAh (Typical) / 31000mAh (Min)

AC Impedance

4.5±1.5mΩ (1KHz AC Method)

Max Continuous Discharge

96A (17.9 min)

Peak Discharge (≤3s)

180A

Max Charge Current

32A (1C, 1.5h)

Standard Charge Current

6.4A (0.2C, 7.5h)

Dimensions (L × W × T)

199.5±1.0 × 119±1.0 × 10±0.3mm

Weight

3500±150g

Terminals

25.0±0.2mm tabs, 20.0±1.0mm exposed

Cycle Life

Condition

Performance

0.5C CC/CV charge (25.2V), 96A discharge (21.3V), 25±3°C

≥240 cycles (≥80% capacity retention)

Operating Temperature Range

Operation

Temperature Range

Current Limit

Standard Charge

10–45°C

≤0.2C (6.4A)

Fast Charge

15–45°C

≤1C (32A)

Standard Discharge

-20–60°C

≤96A

Max Continuous Discharge

10–45°C

≤96A

Storage (≤3 months)

-20–35°C

22.5–23.4V (3.75–3.9V/cell)

Certifications

Complies with GB31241-2014/GB/T 18287-2013 (China National Standard).

Key Features

  • 10C discharge rate for high-power applications.
  • 6S1P configuration with balanced performance.
  • Waterproof warning: Not waterproof; avoid liquid exposure.

Applications

  • Industrial drones and UAVs.
  • High-power RC models.
  • Emergency power systems.
  • 22.8V 32000mAh Drone Battery 96A Discharge 240 Cycles 0

Usage Warnings & Precautions

  • Do not reverse charge or exceed 26.4V (4.4V/cell).
  • Avoid short circuits; use insulated tools during assembly.
  • Do not disassemble or incinerate; risk of electrolyte leakage or fire.
  • Soldering: ≤350°C for ≤3s, max 5 times per tab.

Storage Guidelines

  • Long-term (3+ months): Store at 22.5–23.4V (-20–25°C, ≤75% RH).
  • Activation: Every 3 months with 0.2C charge/discharge cycle.

Warranty & Disclaimer

  • 12-month warranty from shipment date.
  • Void if misused (e.g., overcharge, improper storage, physical damage).
