OiD532347N630 3.7V 630mAh 1C Discharge 500 Cycles Li-ion Battery
OiD532347N630 3.7V 630mAh 1C Discharge 500 Cycles Li-ion Battery OiD532347N630 3.7V 630mAh 1C Discharge 500 Cycles Li-ion Battery

OiD532347N630 3.7V 630mAh 1C Discharge 500 Cycles Li-ion Battery

Product Details:
Place of Origin: China
Brand Name: OiD
Certification: Compliant with: GB/T 18287-2013 (China) IEC 61960 (International) UL 1642 (Safety Standard for Li-ion Batteries)
Model Number: OiD532347N630
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: $0.5 ~ $100.0 / pcs
Delivery Time: 3 ~ 7 days for storage
Payment Terms: TT, L/C, Western Union
Contact Now
  • Detail Information
  • Product Description

Detail Information
Name: Lithium Ion Battery Battery Type: 3.7V, 630mAh Rechargeable
ODM: Free Custom Design For Packs High Energy Density: 250-300Wh/kg
Superior Cold Weather Performance: Reliable In Extreme Cold (-20°C To 60°C) Cycle Life: 500+ Cycles
Charging/ Discharging: 1C/ 1C Flexible Form Factor: Thin, Customizable Pouch Design Lithium Ion Battery
Highlight:

3.7v 2a lithium battery

,

3.7v lithium ion battery

,

630mah 2a lithium battery

Product Description

Product Name

OiD532347N630 Lithium-ion Polymer Battery


Advantages

  • High energy density and lightweight design
  • Stable performance under varied temperature conditions
  • Long cycle life with consistent capacity retention
  • Built-in protection circuit for enhanced safety

Specifications

Parameter

Value

Model

OiD532347N630

Nominal Voltage

3.7V

Typical Capacity

630mAh (0.2C discharge)

Minimum Capacity

600mAh (0.2C discharge)

Charging Voltage

4.2V

Discharge Cut-off Voltage

3.0V

Standard Charging Current

0.2C (126mA)

Max Charging Current

1C (630mA)

Standard Discharging Current

0.2C (126mA)

Max Discharging Current

1C (630mA)

Weight

Approx. 11.3g

Impedance

≤190mΩ


Cycle Life

Condition

Performance

Charge/Discharge Cycles (0.2C)

500 cycles (Capacity ≥80%)

Retention After 28 Days (20±5°C)

Capacity ≥85%


Discharge Curve

OiD532347N630 3.7V 630mAh 1C Discharge 500 Cycles Li-ion Battery 0


Operating Temperature Range

Operation

Temperature Range

Current Limit

Charging

0°C to 45°C

0.2C (0°C–10°C)


0.5C (10°C–20°C)


1.0C (20°C–45°C)

Discharging

-20°C to 60°C

0.2C (-20°C–0°C)


0.5C (0°C–25°C)


1.0C (25°C–60°C)

Storage (50% SOC)

-10°C to 25°C (12 months, ≥85%)

N/A

-10°C to 45°C (6 months, ≥85%)


Certifications

Compliant with:

  • GB/T 18287-2013 (China)
  • IEC 61960 (International)
  • UL 1642 (Safety Standard for Li-ion Batteries)

Key Features

  • Safety Protections: Overcharge, over-discharge, short-circuit, and overcurrent protection.
  • High Efficiency: Low internal resistance (≤190mΩ) for stable power delivery.
  • Environmentally Friendly: RoHS-compliant materials.
  • Customizable: Supports specific client requirements for applications.

Applications

  • Wearable devices (smartwatches, fitness trackers)
  • Medical devices
  • IoT and portable electronics
  • Backup power systems

OiD532347N630 3.7V 630mAh 1C Discharge 500 Cycles Li-ion Battery 1

Usage Warnings & Precautions

  • Do not short-circuit terminals or expose to water.
  • Use only with original chargers (4.2V, 0.2C–1C).
  • Discontinue use if battery shows swelling, leakage, or overheating.
  • Avoid mechanical stress (e.g., crushing, piercing).

Storage Guidelines

  • Store at 20±5°C (recommended) with 50% SOC.
  • Recharge to 60% capacity every 3 months for long-term storage.

Warranty & Disclaimer

  • 12-month warranty from shipment date.
  • Not liable for misuse, improper storage, or unauthorized modifications.
