OID 22000mAh 44.4V 10C LiPo Drone Battery – High Discharge & Efficiency
The OID110168243-22000mAh-44.4V-10C is a high-power lithium polymer battery designed for professional drones and UAVs. Built by Shenzhen Jianheng Technology Co Ltd, this battery delivers exceptional reliability, a stable discharge platform, and high efficiency with ultra-low internal resistance (≤25mΩ). Ideal for applications demanding sustained high current and robust performance.
Key Features
- High Capacity & Power – 22000mAh nominal capacity, 44.4V nominal voltage, 976.8Wh energy
- High Continuous Discharge – 110A continuous (5C rate), 220A peak current
- Low Internal Resistance – ≤25.0mΩ for better efficiency and less heat
- Smart BMS – CAN communication, Bluetooth APP (Android), USB firmware upgrade, cell balancing
- Robust Protection – Over-voltage, under-voltage, over-current, over-temperature protection
- Long Cycle Life – ≥600 cycles at 5C discharge (≥17600mAh retained)
- Wide Temperature Discharge – 0℃ to 60℃ operating range
- Certifications – UN38.3, MSDS certified for safe transport
Technical Specifications
| Parameter |
Value |
| Nominal Voltage |
44.4V |
| Nominal Capacity |
22000mAh (0.5C discharge) |
| Minimum Capacity |
21500mAh |
| Energy |
976.8Wh |
| Standard Charge Current |
0.5C (11A) |
| Fast Charge Current |
2C (44A) max |
| Max Charging Voltage |
50.4V |
| Continuous Discharge Current |
110A |
| Peak Discharge Current |
220A |
| Cut-off Voltage |
36.0V |
| Internal Impedance |
≤25.0mΩ |
| Weight |
≤6200g (with case) |
| Dimensions |
110*168*243 mm |
| Cycle Life |
≥600 cycles (to 80% capacity at 5C discharge) |
| Self-discharge |
≥85% after 1 month at 25℃ |
| High Temp Performance (55℃) |
≥85% capacity |
Safety & Application Notes
- Do not short-circuit, disassemble, or expose to fire above 80℃
- Charge only with compatible charger between 0℃ and 45℃
- Store at 30-60% charge (45.6-48V) in cool dry place (-10℃ to 35℃)
- Recharge every 3 months during long-term storage to maintain 3.7V-3.9V per cell
- Ideal for professional drones, UAVs, robotics, and high-power portable equipment
