Every second your drone stays aloft is a chance to capture critical data, deliver a package, or complete a mission. But nothing cuts that flight short like a battery that sags under load, overheats, or simply dies too soon. As a professional drone operator, you need more than just energy storage—you need reliable, high-throttle endurance. The OID 22000mAh 51.8V 20C smart battery from Shenzhen Jianheng Technology (Jianheng) was designed to solve these real-world challenges. Built for heavy-lift UAVs and industrial drones, this battery delivers consistent high-discharge efficiency, a remarkably flat voltage platform, and an ultra-low internal resistance to keep you flying longer and stronger.
When you're flying a mission-critical sortie, every component must perform. The OID 22000mAh battery uses high-grade 14S1P lithium-ion cells, providing a nominal voltage of 51.8V and a massive 1139.6Wh of energy. With a continuous discharge current of 110A and a peak of 220A (20C rate), this battery handles aggressive throttle punches and high-current demands without voltage sag. Field tests show a 15% longer effective flight time compared to standard packs under the same 80A average load, thanks to its ≤25mΩ internal resistance. Lower resistance means less heat waste and more power to your motors—pure efficiency.
| Parameter | Value |
|---|---|
| Nominal Capacity | 22000mAh (Min: 22000mAh @0.5C) |
| Nominal Voltage | 51.8V (14S) |
| Energy | 1139.6Wh |
| Max Charging Voltage | 58.8V |
| Standard Charge Current | 0.5C (11A) |
| Fast Charge Current | 2C (44A) |
| Continuous Discharge Current | 110A |
| Peak Discharge Current | 220A (20C rate) |
| Internal Impedance | ≤25.0mΩ |
| Weight | Less than 7100g |
| Dimensions (with case) | 168*110*243mm |
| Cycle Life | ≥600 cycles (≥17600mAh remaining) |
The integrated smart BMS is the brain behind the power. It monitors each of the 14 cells with ±10mV accuracy, tracks total voltage within ±0.1V, and measures current at ±3% across full temperature range. This level of precision enables real-time protection against over-voltage (≥4.3V per cell), under-voltage (≤3.0V), over-current (charging >60A), and over-temperature (≥75°C). The BMS also features automatic cell balancing (activating when voltage difference exceeds 100mV), a low-power sleep mode (<800uA shutdown), and Bluetooth communication for Android APP monitoring. You can check remaining capacity (±5% error), individual cell voltages, and fault alerts directly from your phone—no guesswork, just data-driven confidence.
Drones operate in harsh environments. The OID smart battery has passed rigorous vibration (10-55Hz, 0.19-0.38mm amplitude) and drop tests (1m onto hard board) with no fire, no explosion, and no leakage. It comes fully certified with UN38.3 and MSDS, ensuring safe air transport and compliance with global shipping regulations. The battery also features a robust discharge platform with high-temperature tolerance: at 40°C it retains 90% capacity, at 0°C 85%, and at -10°C still delivers 70% of rated capacity—so your drone performs from desert heat to frigid altitudes.
Consider a power line inspection mission requiring 45 minutes of continuous flight with a payload of 3kg. Using a standard 44.4V 16000mAh pack, operators often see voltage drop below 42V after just 25 minutes under load. The OID 51.8V 22000mAh pack maintains a stable output above 48V for over 35 minutes, extending total mission time by 40% and allowing full coverage of 8km of lines in one sortie. With 600 cycle life (still delivering 80% capacity), operational costs drop by more than half compared to lower-grade packs that need replacement every 200 cycles.
For maximum lifespan, charge at 0.5C (11A) to 58.8V with constant current/constant voltage (CC/CV) until current drops below 0.05C. Fast charging at 2C (44A) is supported for rapid turnaround. Store at 30-60% charge (voltage 53.2V-54.6V) in temperatures between -10°C and +35°C, and recharge every 3 months to maintain 3.7V-3.9V per cell. The smart BMS automatically enters standby after 3 minutes of inactivity and shuts down to preserve charge—no parasitic drain worries.
Jianheng (Shenzhen Jianheng Technology Co Ltd) provides full technical support, from pre-sales integration advice to after-sales warranty (12 months or 600 cycles, whichever comes first). Each unit is packaged securely for global shipping from Shenzhen port. For custom configurations or bulk pricing, contact our engineering team.
