OID 21700 10000mAh 21.6V 18C 180A Drone Battery Pack - Model OID21700-10000mAh-21.6V-18C-0113
-
Cell Type21700
-
Nominal Voltage21.6V
-
Nominal Capacity10000mAh
-
Max Discharge Rate18C
-
Max Continuous Current180A
-
Internal Resistance≤10mΩ
-
Operating Temperature-40℃ To +60℃
-
Cycle Life≥1000 Times
-
Place of OriginChina
-
Brand NameOID
-
CertificationUN38.3, MSDS
-
Model NumberOID21700-10000mAh-21.6V-18C-0113
-
Minimum Order Quantity1pcs
-
PriceContact for best price
-
Packaging DetailsStandard export packaging / Customized box
-
Delivery Time5-10 working days after order confirmation
-
Payment TermsL/C,D/A,D/P,T/T,Western Union
-
Supply Ability100000 pieces per month
OID 21700 10000mAh 21.6V 18C 180A Drone Battery Pack - Model OID21700-10000mAh-21.6V-18C-0113
OID 21700 10000mAh 21.6V 18C High-Rate Low-Temperature Drone Battery Pack
The OID21700-10000mAh-21.6V-18C-0113 is a high-performance drone battery pack designed for professional UAV applications. It delivers ultra-high discharge current, excellent low-temperature performance, and low internal resistance, ensuring stable power supply in demanding environments.
Manufacturer: Shenzhen Jianheng Technology Co Ltd (Jianheng) - Tel: 0086 137 2555 9416 - Email: alan@liion-batt.com - Address: 20F 2# Bld. Zhenhuan Rd. Pingshan, Shenzhen, China
Detailed Specifications
| Parameter | Value |
|---|---|
| Model Number | OID21700-10000mAh-21.6V-18C-0113 |
| Cell Type | 21700 Lithium-ion |
| Nominal Voltage | 21.6V |
| Nominal Capacity | 10000mAh |
| Maximum Discharge Rate | 18C |
| Maximum Continuous Discharge Current | 180A |
| Internal Resistance | ≤10mΩ |
| Operating Temperature Range | -40℃ to +60℃ (charge: 0℃ to +45℃) |
| Storage Temperature Range | -20℃ to +35℃ |
| Cycle Life | ≥1000 cycles at 1C charge/discharge |
| Weight | Approx. 780g (varies by configuration) |
| Dimensions | Customizable per UAV specifications |
Test Parameters
| Test Item | Test Condition | Requirement |
|---|---|---|
| Discharge Performance at 18C | 18C constant current discharge to 16.2V at 25℃ | Discharge time ≥ 3 min, capacity ≥ 80% rated |
| Low Temperature Discharge at -40℃ | Discharge at 1C after storage at -40℃ for 24h | Capacity ≥ 60% rated, no abnormal heating |
| Internal Resistance | AC 1kHz test | ≤10mΩ |
| High Rate Cycle Life | 5C charge (CC-CV) / 18C discharge, 200 cycles at 25℃ | Remaining capacity ≥ 80% rated |
| Overcharge Test | Charge at 3 times standard current to 25.8V | No fire, no explosion |
| Short Circuit Test | External short circuit at 25℃, resistance ≤ 50mΩ | No fire, no explosion, temperature rise ≤ 150℃ |
Key Features
- Ultra-high 18C discharge rate delivers 180A continuous current for high-power UAVs.
- Low internal resistance below 10mΩ improves energy efficiency and reduces heat generation.
- Excellent low-temperature performance down to -40℃ ensures reliable operation in cold climates.
- High energy density 21700 lithium-ion cells provide extended flight time.
- Robust battery management system (BMS) protects against overcharge, overdischarge, overcurrent and short circuit.
- Customizable capacity, voltage and dimensions for specific drone platforms.
Safety and Applications
Safety: This battery pack is designed and tested in accordance with UN38.3 and MSDS requirements. It is equipped with protection functions and high-quality materials to ensure safe operation during normal use, transportation and storage. Strict quality control procedures are applied in every production step.
Applications: Suitable for agricultural drones, surveying and mapping UAVs, industrial inspection drones, delivery drones and other high-power unmanned aerial vehicles. Also applicable for robotics and high-rate discharge portable devices.
